Lift Station Controller – LsPRO™
The LsPRO Lift Station Controller is BCI Technologies’ flagship packaged solution for wastewater lift station automation. Designed for ease of use, rapid deployment, and long-term durability, the LsPRO combines advanced control functionality with an intuitive interface tailored for operators and technicians. It supports multiple pump configurations, level monitoring, alarm management, and remote telemetry—all within a single, compact enclosure.
The controller is engineered to integrate easily with both new installations and retrofits, making it a cost-effective choice for municipalities and utilities seeking reliability without complex programming. Built using industrial-grade components and backed by years of lift station control experience, the LsPRO minimizes downtime and enhances system responsiveness.
Proven Performance in the Field
The LsPRO has been successfully deployed in hundreds of lift stations, delivering consistent, worry-free operation under demanding conditions. Its robust design ensures stable performance in harsh environments, while its modular architecture allows for future scalability and upgrades as system requirements evolve.
With support for remote access and integration with leading SCADA platforms, the LsPRO offers seamless visibility and control across your lift station network. BCI also provides full-service support—from configuration and commissioning to ongoing technical assistance—ensuring that each installation is optimized for long-term performance. This end-to-end approach allows our clients to focus on operations while we handle the complexities of automation, compliance, and communication.
Whether deployed in small communities or large-scale networks, the LsPRO provides the confidence and control utilities need to keep critical infrastructure running smoothly.
Standard Features
- DNP3 and Modbus Communication
- RTU Event Logging (20000 events when utilizing DNP3 Protocol)
- Serial and Ethernet Connectivity
- USB Configuration
- 16 Digital Inputs
- 10 Dry Contact Relay outputs
- 8 Analog Inputs (4-20ma)
- Multiple communication options (Conventional Radio, Spread Spectrum, Ethernet, Cellular)
I/O Points
- Pump Run and Fail inputs
- Pump Start/Stop
- Pump HOA Switch status
- Float Status
- Generator Run/Fail inputs
- Generator Start/Stop
- Generator Fuel Level (4-20 input, signal supplied by customer)
- Phase Monitor / Utility Power
- Local Horn/Light control
- Level Transducer
Typical Applications
- Duplex/Triplex Pump Controller
- Float or Level Transducer (4-20ma) Control
- Pump Alternation
- Pump Power Data (KWH, Amps, Voltage) with optional TeSys T
- Optional Local HMI and Configuration
The LsPRO Lift Station Controller is a complete duplex/triplex lift station controller that supports multiple station configurations and is built on the Schneider Electric SCADAPack 474 Series RTU and Allen Bradley MicroLogix 1400 Series PLC. It is available in two configurations; a standard configuration (LsPRO) and an expanded configuration (LsPRO/EX) that adds two TeSys-T modules.
Technical Specifications
| Input Power | 11 - 30VDC, 3.5W typical |
| Operating Temperature | -40°C to +70°C (-40°F to 158°F) |
| Packaging | Corrosion resistant zinc-plated steel with black enamel paint |
| Analog Inputs | 8, 0-20/4-20mA / 0-5/0-10V |
| Digital I/O | 16 inputs: 12/24V,48V, 115/125V, 240V digital inputs and 10 relay outputs: dry contact or DC solid state, dry contact rating: 3A, 30VDC |
| I/O Terminations | 5, 6 and 9-pole removable terminal blocks, 12 to 22AWG, 15a contacts |
| Dimensions | 5.65 inch (144mm) wide, 6.50 inch (165mm) high, 2.80 inch (72mm) deep |
